    calloutLineWidth Property
    In This Topic
    Specifies the thickness of a callout's border line.
    Syntax
    ASP.NET Ajax JavaScript (Specification)
    function get_calloutLineWidth() : Number
    function set_calloutLineWidth(value : Number)
    ASP.NET Ajax JavaScript (Usage)
    var resultVar = instanceOfMark.get_calloutLineWidth();
    Example

    This JavaScript code will create the mark shown in the image on this page.

    // Create a new text mark.
    var mark = new ImageGear.Web.UI.Mark(ImageGear.Web.UI.MarkType.Text);

    // Set various properties.
    mark.set_rectangle({ x: 100, y: 200, width: 300, height: 150 });
    mark.set_text('This text mark has a distinctly-styled callout.');
    mark.set_lineWidth(6);
    mark.set_fontSize(24);
    mark.set_calloutVisible(true);
    mark.set_calloutType(ImageGear.Web.UI.CalloutType.Line);
    mark.set_calloutPoint(new ImageGear.Web.UI.Point(275, 225));
    mark.set_calloutLineIsDistinct(true);
    mark.set_calloutLineWidth(4);
    mark.set_calloutLineStyle(ImageGear.Web.UI.LineStyle.Dash);
    mark.set_calloutLineColor('#b4b400');
    mark.set_fillVisible(false);
    mark.set_fontStyle(ImageGear.Web.UI.FontStyle.Bold);
    mark.set_textOpacity(127);

    // Add the mark to the page.
    // Adding it after setting the properties avoids a lot of needless markChanged events.
    $find('PageView1').get_artPage().addMark(mark);


    Remarks

    This property specifies the thickness of a callout's border line. If calloutLineIsDistinct or calloutVisible are false, this property will have no effect on the visual appearance of the mark. If you change the value of this property, this object will raise its propertyChanged event.

    This figure shows a text mark whose callout has an outline that is thinner than the rest of the mark.

    Mark types: This property is valid for Text marks.
    Valid values: a number between 0 to 50 (inclusive). If you set this property to 0, the line may not be visible.
    Default value: 1

    ImageGear for .NET name: Callout.Border.Width
    NotateXpress (version 10) name: N/A
