Micro QR
Supported Barcode Types > Barcode Types > Micro QR

Micro QR Description

Micro QR codes are a variant of QR codes that have a restricted size and capacity to limit the data. Micro QR codes can contain numeric, alphanumeric, byte and Kanji data and offer three levels of error correction. QR Codes have three finder patterns while Micro QR has one finder pattern and a limited amount of data that can be encoded. This allows them to use less space and contain a smaller and more focused amount of data.

Error Correction

This barcode uses Reed-Solomon error detection and correction scheme: L - 7% error recovery M - 15% error recovery Q - 25% error recovery Error correction for Micro QR codes allows for the reader to restore data if parts of the code is damaged and cannot be read. The error correction is measured as a ratio of the number codewords that can be read to the number of codewords that cannot be read.

Managing Organization

The QR Code is governed by ISO/IEC 18004:2015. 1

Version Info

Micro QR Codes contain a single finder pattern located at the top left corner of the barcode and there are four versions of Micro QR.

Micro QR Structure

The horizontal and vertical timing patterns consisting of a one module wide row or column and alternates between dark and light modules. This allows the symbol density and version density to be determined

The quiet zone should be clear of any other markings and should match the value of the light module.

M1 M2 M3 M4

Barcode Capacity

There are four versions of Micro QR and the support the following data capacity:

Version Error Correction Numeric Alphanumeric Byte Kanji
M1 Error Detection Only 5 None None None
M2 L 10 6 None None
M2 M 8 5 None None
M3 L 23 14 9 6
M3 M 18 11 7 4
M4 L 35 21 15 9
M4 M 30 18 13 8
M4 Q 21 13 9 5

Data Masking

To ensure reliable QR Code reading it is best for QR modules to be arranged in balanced pattern between the dark and light modules, by creating alternating masking patterns this will help prevent large blank areas that could cause incorrect results when reading.

Related Barcodes

Micro QR Codes are a condensed version of the QR Code.

Differences in Micro QR and QR:

Micro QR QR
Three levels of error correction Four levels of error correction
Requires one finder pattern Requires three finder patterns
Can contain a maximum of 128 bits Can contain a maximum of 23,648 bits

References

  1. "QR Code Bar Code Symbology Specification." ISO/IEC 18004:2015, ISO/IEC, Feb. 2015, www.iso.org/standard/62021.html.
